SSD7184

PCIe 3.0 x16 Hybrid 8-Port U.2 NVMe RAID HBA


The Industry's Most Flexible 8-Port NVMe RAID HBA


Massive Storage Capacity & Performance

The SSD7184 is the industry’s first 8-Channel Hybrid Internal/External PCIe 3.0 NVMe RAID controller. This unique port configuration allows the SSD7184 to support both internal and external storage configurations; ideal for compact platforms that require a built-in option for storage expansion or the flexibility of a removable/portable storage device. The 4x SFF-8643 connectors can support up to 4 internal U.2 drives, while the external SFF-8644 ports were designed for use with external NVMe storage enclosures, such as our SSD6500 series.


Performance Focused, Platform Independent NVMe RAID Solution

HighPoint NVMe RAID controllers are fully independent NVMe storage solutions. SSD7000 series PCIe Gen3 NVMe RAID HBAs do not require a hardware environment with Bifurcation support and can be easily integrated into any AMD or Intel computing platform with a dedicated PCIe 3.0 or 4.0 x16 slot. The SSD7184 leverages intelligent PCIe switch technology to allocate up to 4x dedicated lanes to each NVMe SSD to ensure maximum transfer speed and immediate response time.


Flexible 2.5" U.2 Form Factor

The U.2 ports provide customers with a great deal of flexibility when selecting an appropriate hardware platform. The connectors are compatible with a wide selection of 2.5” form-factor rackmount chassis available in today’s marketplace. In addition, the industry standard SFF-8639 connectors accept cables of varying length, which allow the SSD7184 RAID HBA to be easily integrated into custom chassis designs. This design simplifies field upgrades and maintenance sessions, and is ideal for chassis that require removable drive trays for quick access to storage devices.


Industy Proven NVMe RAID Engine

The SSD7184 is powered by HighPoint's industry proven NVMe RAID stack and is capable of supporting RAID 0, 1, 10 arrays and single-drives, including mixed configurations of single-disks and arrays, or multiple arrays.


Specifications

Product feature

Bus Interface

PCI-Express 3.0 x16

Number of Channel / Port

8x Intenal U.2 NVMe port and 4x External U.2 NVMe port

Port Type

4x SFF-8643 Mini-SAS HD 4x SFF-8644 Mini-SAS HD

Data Transfer Rates

8GT/s

Number of Devices

8x U.2/U.3 NVMe SSD

SSD Form Factor

2.5" U.2

External Power Support

N/A

Form Factor

Low profile

Card Dimensions

6.50" (W) x 2.71"(H) x 0.91" (D)

Card Weight

0.95 lbs.

Warranty

2 Years

Supported Operating Systems

Windows

Windows 11, 10; Windows Server 2022, 2019, 2016; Microsoft Hyper-V; Only supports 64 bit operating system.

Linux

RHEL/Debian/Ubuntu/Fedora/Proxmox/Rocky Linux(Linux kernel 3.10 and later) Only supports 64 bit operating system.

macOS

For macOS support, please contact Sales Support (sales@highpoint-tech.com)

System Requirements

Mac Platforms:

For macOS support, please contact Sales Support (sales@highpoint-tech.com)

PC Platforms:

Any PC Systems or Motherboard with an industry standard PCIe x16 physical Slot (Bifurcation is not required)

Secure Boot(PC platforms)

Windows: Support Secure Boot enable and disable
Linux:Support Secure Boot disable

Cooling System

Anodized aluminum heatsink with a built-in Low-Noise fan

Fan Control

Yes (Windows)

NVMe Configurations

RAID Support

Single, RAID 0, 1, 10

TRIM RAID Support

Single, RAID 0, 1, 10

Storage Mode - NVMe

Data RAID(Non-Bootable)

Windows, Linux (Linux Driver can be installed via internet/network connection)

NVMe RAID Management

Management Suites

WebGUI (Browser-Based management tool )
CLI (Command Line Interface- scriptable configuration tool)
API package

SMTP Email Alert Notification

Yes

Alarm Buzzer

Yes

Storage Health Inspector

Yes

NVMe SMART status

Yes

Automatic and configurable RAID Rebuilding Priority

Yes

Auto resume incomplete rebuilding after

Yes

Single-RAID or Multi-RAID Arrays per Controller

Yes

Cross-Sync RAID Solution Across Controllers

No

Advanced RAID features

Flash ROM for Upgradeable UEFI

No

Bootable RAID Array

No

Multiple RAID Partitions supported

Yes

Online Array Roaming

Yes

RAID Quick Initialization for fast array setup

Yes

Global Hot Spare Disk support

Yes

Operating Environment

Work Temp

+5°C ~ + 55°C

Storage Temp

-20°C ~ +80°C

Operating Voltage

PCI-e: 12V, 3.3V

Power

Typical: 7.13W

MTBF (Mean Time Before Failure)

920,585 Hours

Certification / Approval

CE, FCC, RoHS, REACH, WEEE

Kit Contents

1x SSD7184
1x Quick Installation Guide
1x Low-Profile bracket
