Introducing the RocketMate 220

The RocketMate 220 is a stand-alone, pocket-sized, PCIe 3.0 x4 Dual-M.2 NVMe Host-RAID enclosure adapter; it is designed for professional and industrial applications that require a compact, NVMe host-RAID solution built to withstand demanding work environments. Native In-Box driver support ensures plug & play compatibility with any modern PC based operating system and VM platform.

The universal 2.5” form factor and SFF-8639 U.2 connectivity allows RocketMate 220 enclosures to be easily integrated into a wide range of industry standard enclosures, backplanes, drive bays and mobile racks.

Key Features

  • 2.5” form factor NVMe RAID Solution for PC platforms

  • Up to 8000MB/s of transfer performance

  • Accepts up to 2x 2242/2260/2280 M.2 NVMe SSDs

  • Integrated Host RAID Technology (0, 1, JBOD)

  • Built-In RAID Switch

  • Power Loss Protection (PLP)

  • Driverless, Plug & Play Installation

  • Natively supported VMware, Linux & Windows platforms

The RocketMate 220 is a stand-alone, pocket-sized, PCIe 3.0 x4 Dual-M.2 NVMe Host-RAID enclosure adapter; it is designed for professional and industrial applications that require a compact, NVMe host-RAID solution built to withstand demanding work environments. Native In-Box driver support ensures plug & play compatibility with any modern PC based operating system and VM platform.  The universal 2.5” form factor and SFF-8639 U.2 connectivity allows RocketMate 220 enclosures to be easily integrated into a wide range of industry standard enclosures, backplanes, drive bays and mobile racks.

Unique Hardware Architecture

Portable, Mass Storage Solution



Up to 16TB of Portable NVMe RAID Storage!

The two M.2 slots can support  any off-the-shelf PCIe Gen3 or Gen4 2242/2260/2280 M.2 NVMe SSD, and do not impose any capacity limitations

Integrated RAID 0 & 1 Capability with Hardware Switch

The RocketMate 220 features integrated host RAID technology, that is capable of supporting RAID 0 (stripe), RAID 1 (mirroring) and single disk configurations.    The underside of the RocketMate 220 enclosure features a built-in hardware switch that enables users to configure an array without the need for an operating system or software application.  Users can easily toggle between three modes using the dial: RAID 0 Striping, RAID 1 Mirroring, and JBOD (single disk).

The RocketMate 220 features integrated host RAID technology, that is capable of supporting RAID 0 (stripe), RAID 1 (mirroring) and single disk configurations.



The underside of the RocketMate 220 enclosure features a built-in hardware switch that enables users to configure an array without the need for an operating system or software application.

Users can easily toggle between three modes using the dial: RAID 0 Striping, RAID 1 Mirroring, and JBOD (single disk).

Ideal Bootable Drive Solution for Virtual Machine Platforms

The RocketMate 220 Dual M.2 NVMe RAID enclosure is natively supported by all major VM platforms, such as VMware, Proxmox, Hyper-V and Citrix Hypervisor. Native, In-Box driver support ensures that any RAID array hosted by the RocketMate 220 is absolutely 100% transparent to the VM Platform; arrays will be recognized as ordinary single drives, and can be immediately used to install the VM host or virtual machines.    The RocketMate 220 Adapter-Enclosure is compatible with most modern PC-based server and workstation platforms; the compact, industry-standard 2.5” form factor is easily installed into any drive bay, mobile rack, rackmount chassis or enclosure with SFF-8643 or M.2 connectivity.

The RocketMate 220 Dual M.2 NVMe RAID enclosure is natively supported by all major VM platforms, such as VMware, Proxmox, Hyper-V and Citrix Hypervisor. Native, In-Box driver support ensures that any RAID array hosted by the RocketMate 220 is absolutely 100% transparent to the VM Platform; arrays will be recognized as ordinary single drives, and can be immediately used to install the VM host or virtual machines.



The RocketMate 220 Adapter-Enclosure is compatible with most modern PC-based server and workstation platforms; the compact, industry-standard 2.5” form factor is easily installed into any drive bay, mobile rack, rackmount chassis or enclosure with SFF-8643 or M.2 connectivity.

Enterprise Class Reliability: Power Loss Protection

The RocketMate 220 incorporates a bank of capacitors that are used to flush data stored in NVMe cache to the flash memory in the event of a sudden loss of power.  This helps prevent the loss of in-transit data during a power outage of PSU failure.  ​

The RocketMate 220 incorporates a bank of capacitors that are used to flush data stored in NVMe cache to the flash memory in the event of a sudden loss of power.

This helps prevent the loss of in-transit data during a power outage of PSU failure.

Easy DIY Solution!

Convert a U.2 Device into a Massive Storage or Mirrored System Drive

The RocketMate 220 Host-RAID capability allows you to instantly transform a U.2 drive into a massive 16TB storage device, or ultra-secure Mirrored system disk using the built-in hardware switch.

The dial is located at the bottom of the enclosure and can be easily adjusted using a small flat-head screwdriver or similar hand tool. Three modes are provided; RAID 0 Striping for applications that require maximum performance and capacity, redundant RAID 1 Mirroring to protect bootable volumes, and JBOD for single disk, non-RAID configurations.

Bootable RAID Support for any Modern VM or OS Platforms

M.2 SSDs and RAID arrays hosted by the RocketMate 220 require no device driver or software application and are natively supported by all current PC operating systems and VM platforms such as Windows 11, Windows Server 2022, Hyper-V, VMware, Proxmox, Citrix Hypervisor, and Linux distributions that utilize kernel v3.10 and later.
