Specifications

SSD7505 SSD7540
Bus Interface PCI-Express 4.0 x16 PCI-Express 4.0 x16
Number of Channel / Port 4x M.2 NVMe port (Dedicated PCIe 4.0 x4 per port) 8x M.2 NVMe port
Data Transfer Rates 16GT / 16Gbps per lane 16GT / 16Gbps per lane
Number of Devices 4x M.2 NVMe SSD 8x M.2 NVMe SSD
SSD Form Factor 2242/2260/2280/22110 (supports single & double sided) 2242/2260/2280 (supports single & double sided)
Form Factor Full Height Full Height
Card Dimensions 7.68"(W) x 4.41"(H) x 0.81"(D) 11.22'' (W) x 4.37'' (H) x 0.83'' (D)
Card Weight 1.32 lbs. (600g) 1.70 lbs (772g)
SSD7505 SSD7540
Windows Windows 10, Windows Server 2016 or later, Microsoft Hyper-V Windows 10, Windows Server 2016 or later, Microsoft Hyper-V
Linux Linux Kernel 3.10 or later Linux Kernel 3.10 or later
macOS macOS 10.13 or later macOS 10.13 or later
System Requirements Mac Platforms:
• Apple Mac Pro Systems: 2012 and later Mac Pro systems; 5.1, 7.1 (2019) / Note: PCIe 4.0 required for maximum performance
• Apple M1 Platform compatible
• Thunderbolt™ 3 Connectivity via Thunderbolt™ Expansion chassis: RocketStor6661A
Mac Platforms: • Apple Mac Pro Systems: 2012 and later Mac Pro systems; 5.1, 7.1 (2019) / Note: PCIe 4.0 required for maximum performance
• Apple M1 Platform compatible
PC Platforms:
• Any PC Systems or Motherboard with an industry standard PCIe x16 physical Slot (Bifurcation is not required). Note: PCIe 4.0 required for maximum performance.
• Thunderbolt™ 3 Connectivity (requires a PC platform with a Thunderbolt 3 port) & Thunderbolt™ Expansion chassis: RocketStor6661A
PC Platforms: • Any PC Systems or Motherboard with an industry standard PCIe x16 physical Slot (Bifurcation is not required). Note: PCIe 4.0 required for maximum performance.
Cooling System Full-Length Anodized Aluminum Heat sink with built-in Low-Noise fan Full-Length Anodized Aluminum Heat sink with built-in Low-Noise fan
Fan Control Yes (Windows, Mac) Yes (Windows, Mac)
SSD7505 SSD7540
RAID Support Single, RAID 0, 1, 1/0 Single, RAID 0, 1, 1/0
TRIM RAID Support Single, RAID 0, 1, 1/0 Single, RAID 0, 1, 1/0
Data RAID(Non-Bootable) Windows, Linux, macOS Windows, Linux, macOS
Boot RAID ● Windows
● Linux
● MacOS(Only supports up to macOS 10.15; Bootable using one non-RAID M.2 SSD as boot drive with the other SSDs configured as independent volumes or as a highpoint RAID.)
● Windows
● Linux
● MacOS(Only supports up to macOS 10.15; Bootable using one non-RAID M.2 SSD as boot drive with the other SSDs configured as independent volumes or as a highpoint RAID.)
SSD7505 SSD7540
Management Suites Browser-Based management tool Browser-Based management tool
CLI (Command Line Interface- scriptable configuration tool)  CLI (Command Line Interface- scriptable configuration tool)
API package API package
SMTP Email Alert Notification Yes Yes
Alarm Buzzer Yes Yes
Storage Health Inspector Yes Yes
NVMe SMART status Yes Yes
Automatic and configurable RAID Rebuilding Priority Yes Yes
Auto resume incomplete rebuilding after Yes Yes
Single-RAID or Multi-RAID Arrays per Controller Yes Yes
Cross-Sync RAID Solution Across Controllers Yes (Windows, Linux, Mac) n/a
SSD7505 SSD7540
Work Temp +5°C ~ + 55°C +5°C ~ + 55°C
Storage Temp -20°C ~ +80°C -20°C ~ +80°C
Operating Voltage PCI-e: 12V, 3.3V PCI-e: 12V, 3.3V
Power Typical: 17.72W Typical: 15.04W
MTBF (Mean Time Before Failure) 920,585 Hours 920,585 Hours
Certification / Approval CE, FCC, RoHS, REACH, WEEE CE, FCC, RoHS, REACH, WEEE
SSD7505 SSD7540
QIG QIG
